Create a home theater with audiophile sound
Some music and video enthusiasts may think you can't get true-to-life music quality along with a realistic theater experience from a single receiver. Denon's AVR-X3800H is here to show you that you can. With nine channels of robust amplification and high-resolution audio processing, this surround sound powerhouse can give you the best of both worlds.

What's new with Denon
With the 'X3800H, Denon has expanded its feature set for the growing 8K video and next-gen gaming market. The previous lineup of Denon home theater receivers introduced limited 8K processing, along with gaming features like Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), and Quick Frame Transport (QFT). These features have been applied to the AVR-X3800H on all six HDMI inputs and two of the three HDMI outputs, so you can accommodate even more modern tech into your system.

More options for system calibration
Denon still includes the excellent Audyssey speaker calibration suite to tune your theater sound to your space. Coming in 2023, you'll also have the option to purchase and download the Dirac Live® advanced speaker calibration program to your Mac® or PC. Fine-tune the output of your system to match the unique sonic characteristics of your space and bring your surround sound to exciting new heights.

Plentiful options for speaker setups
The AVR-X3800H has outputs for 11 speakers, and it can power up to nine at the same time. This gives you the flexibility to choose from different home theater and wired multi-room music configurations.

Use all nine channels in a 5.1.4 or 7.1.2 Dolby Atmos® or DTS:X™ system, or go with a more modest surround sound setup such as 5.1ch or 7.1ch and repurpose the extra channels for music in another zone. If you don't have height speakers, you can still enjoy simulated overhead effects with Dolby Atmos Height Virtualization.

You can even expand your system beyond the receiver's nine built-in channels of power. Its 11-channel RCA preamp outputs make it a respectable preamp/processor if you want to add separate amplifiers.

4 subwoofer outputs
One of the most exciting features on this new receiver, in my opinion, is the inclusion of four (you read that right, FOUR) subwoofer outputs! Fellow bass-heads rejoice! Using multiple powered subs obviously gives you more bass, but also more balanced bass. Choose the "Standard" subwoofer setting for evenly distributed bass performance throughout the room, or "Directional" to tailor each sub's bass performance to the closest speaker.

Feature Summary

• Supports 9.4 or 5.1.4-Channel Audio
• Up to 105W per Channel
• Up to 8K HDR Video on All HDMI Inputs
• Use with HEOS for Multi-Room Audio
• Dolby Atmos, DTS:X & IMAX Enhanced
• Pre-Amplifier Mode
• 11.4-Channel Processing
• Wi-Fi & Bluetooth Connectivity
• Audyssey Room Calibration
• Next-Gen Gaming Support
• 2nd Zone
• MM Moving Magnet Phono input
• Advanced room calibration with Audyssey MultEQ® XT32 multi-channel processing

Channels: 9.4

Power Output per Channel2-Channel Driven:
95 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD
125 W at 6 Ohms / 1 kHz / 0.7% THD
1-Channel Driven:
185 W at 6 Ohms / 1 kHz / 10% THD

Wireless Connectivity: Wireless Audio ProtocolsAirPlay 2, HEOS, Roon Ready, Spotify Connect

Virtual Assistant: Apple AirPlay, Works with Alexa, Works with Google Assistant, Josh.ai, Siri

Tuner Type: AM, FM

Maximum Dimensions
Antenna:Horizontal: (W x D x H) in mm 434 x 389 x 167
Antenna:Vertical :(W x D x H) in mm 434 x 389 x 236
w/o Antenna :(W x D x H) in mm 434 x 379x 167

Weight: 12.5 kg

HDMI
HDMI Inputs: 6
HDCP2.3 support - Yes
HDMI Outputs: Main - 2 Zone - 1
ALLM (Auto Low Latency Mode) Pass-Through for Gaming - Yes
Quick Media Switching - Yes
3D Signal Pass-through - Yes
GUI Overlay - Yes
DSD Audio Capability - Yes
Enhanced ARC - Yes
Auto LipSync - Yes

Multiroom
Multi-Room Zones - 2
Zone HDMI Output from HDMI Source - Yes
DC Trigger Output - 1
Zone Audio Output: Pre-Out - Yes
RS232 Control - Yes
App Control - Yes

WARRANTY

2 year warranty

DELIVERY

Free Delivery (Australia Wide)

2-3 working days processing period
